20″ wide ductile iron slotted trench drain grate


Call for availability

SKU: 20B24DI Categories: ,


Cast ductile iron slotted trench drain grate – coated black – 20″ wide x 24″ long x 1.5″ thick – rated for DIN load class D.


This is one of our most popular 20″ wide trench drain grates.  It is typically used on an 18″ wide prefabricated trench drain or 18″ wide catch basin.  The larger openings plug less often making this grate ideal for the intake of large amounts of water.  Typical uses are trench drains in loading docks, parking lots, parking garages, industrial and manufacturing facilities, and any other area where a high intake volume is required.


Additional information

Weight 62.2 lbs
Dimensions 24 × 20 × 1.5 in
Documents Click here for Specification Sheet
