2 inch wide precast trench drain


This general purpose 2 inch wide channel drain system can handle flows in the 0.3 cfs (150 gpm) range.  Our channel drains sections come in pre-sloped 8′ lengths with heavy plywood cover  and installation aides standard.  Offered with a wide selection of frames and 3″ wide channel drain grates to meet any design requirement.  This channel drain is typically used in patios, pool decks, residential projects, and other commercial projects where a low profile is desired.


2 inch wide precast trench drain

2″ wide interior trench drain.  Can be sloped from 2″ to 12″ deep typical (contact us for pricing and availability on deeper depths).  2 inch wide trench drains can be used for flows up to 0.3 cfs (150 gpm).  Trench drain frame options are light duty plastic, medium duty galvanized steel, and medium duty stainless steel.  Comes complete with trench drain installation brackets, plywood covers, end plates and outlets.  Our 2 inch wide trench drains accept any of the 3″ wide trench drain grates.  This narrow 2 inch trench drain system is useful when a low profile trench drain is desired but access for cleaning the trench is still required.


Typical 2 inch wide precast trench drain applications:



Elevated patios and decks




Additional information

Weight 45 lbs
Dimensions 96 × 5 × 10 in
PRODUCT INFO Trench width: 2" I.D. Grate width: 2 7/8" wide Section length: 8' long Depth: varies from 2" to 12" Slope: 0.5% typical (any other slope as required) Trench Material:  Polyester glass fiber reinforced polymer concrete Frame Material:  Various loadings, materials, and finishes offered.   Note:  after placing order a customer service representative will call you to confirm the details of your order and that it is configured in the manner that you choose.

LDTP light duty plastic frame, MDGS Medium Duty Galvanized Steel Frame, MDSS medium duty stainless steel frame

RETURN & REFUND POLICY This product is assembled to order and will be custom built to your specifications.  As a result the trench is non-returnable.  Grates and locking hardware are returnable.  If they are in re-saleable condition they will be accepted and will be assessed a 25% restocking fee.
SHIPPING INFO Shipping of the DuraTrench product is by truck freight only due to the long section lengths.  A forklift is recommended to unload the materials, however, lift gate service is available for an additional charge.
